| Order Code |
Item |
Parts |
| UB200 |
Body (Choose the power cord please) |
○ |
| MS2F |
Binocular, Interpupillary distance 52-75mm |
○ |
| E1020PA |
High eye-point plan eyepiece WF10X/20 |
○○ |
| E1613PB |
Plan eyepiece WF16X/13 |
○○ |
| E1020GA |
High eye-point plan eyepiece WF10X/20 (Pointer) |
○ |
| E1020RA |
Reticule Eyepiece, Cross WF10X/20 |
○ |
| WB-X4C |
Infinity Achromatic Objective 4X N.A.0.13 |
○ |
| WB-X10C |
Infinity Achromatic Objective 10X N.A. 0.30 |
○ |
| WB-X40C |
Infinity Achromatic Objective 40X(S) N.A.0.70 |
○ |
| WB-X100C |
Infinity Achromatic Objective 100X(S)/(Oil) N.A. 1.25 |
○ |
| WB-X4C-P |
Infinity Plan Achromatic Objective (Economical) 4X N.A.0.13 |
○ |
| WB-X10C-P |
Infinity Plan Achromatic Objective (Economical) 10X N.A.0.30 |
○ |
| WB-X40C-P |
Infinity Plan Achromatic Objective (Economical) 40X(S) N.A.0.70 |
○ |
| WB-X100C-P |
Infinity Plan Achromatic Objective (Economical) 100X(S) (oil) N.A.1.25 |
○ |
| WB-P2C |
Infinity Plan Achromatic Objective 2X |
○ |
| WB-P4C |
Infinity Plan Achromatic Objective 4X |
○ |
| WB-P10C |
Infinity Plan Achromatic Objective 10X |
○ |
| WB-P02C |
Infinity Plan Achromatic Objective 20X |
○ |
| WB-P40C |
Infinity Plan Achromatic Objective 40X (S) |
○ |
| WB-P60C |
Infinity Plan Achromatic Objective 60X (S) |
○ |
| WB-P100C |
Infinity Plan Achromatic Objective 100X (S) (Oil) |
○ |
| ZT2 |
Mechanical Stage, right handed, 156X138mm, movement range 76X54mm |
○ |
| ZT2B |
Rackless Stage, right handed, 185X177mm, movement range 75X50mm |
○ |
| ZQ480 |
Quadruple Nosepiece, inward facing |
○ |
| ZQ580 |
Quintuple Nosepiece, inward facing |
○ |
| JG2C |
Abbe Condenser |
○ |
| KL2B |
Kohler Illuminator (No field diaphragm) |
○ |
| KL3A |
Kohler Illuminator (with field diaphragm) |
○ |
| DQ2 |
for 6V 20W Halogen Lamps |
○ |
| DQ2A |
for 6V 30W Halogen Lamps |
○ |
| DQLC2C |
3W LED Electric Device (with Rechargeable Batteries) |
○ |
| DQL2C |
3W LED Electric Device |
○ |
| LA5-0011 |
Blue Filter (φ38) (LED Lamp without Filter) |
○ |
| LU5-0011 |
Green Filter (φ38) |
○ |
| LH5-0011 |
Yellow Filter (φ38) |
○ |
| LB5-0011 |
Ground Glass (φ38) |
○ |
| BZ-0022A |
6V 20W Osram Lamp |
○ |
| BZ-0022 |
6V 20W Halogen Lamp Made in China |
○ |
| BZ-0023 |
250V/3.15A Φ5X20 fuse |
○○○ |
| BZ-0022B |
6V 30W Halogen Lamp |
○ |
| BZ-0022C |
6V 30W Osram Halogen Lamp |
○ |
| DQL2B-2000 |
3W LED Lamps |
○ |
| BZ-0027 |
Immersion Oil |
○ |
| WJZ-UB100I/200I |
Dust Cover |
○ |
| BZ2-0018 |
φ2mm Allen screw driver |
○ |
| BZ-0021 |
Power Cord |
○ |
| ○ means optional configuration |
