Product Details:
Payment & Shipping Terms:
|
| Model: | XSP-5.0 | Type: | LCD Screen |
|---|---|---|---|
| Colour: | Black | USB: | 2.0 |
| Application: | For Optical Microscope | Pixel: | 5.0 Million |
| High Light: | cmos microscope camera,usb microscope camera |
||
● Built-in measurement, support length/distance betwwen two circle/geometric measurement etc. The result can be accurate to 1/100 micron, and even can easily measure very samll cells.
● Click the button to directly record and shoot 1080P & 60FPS video, the file is stored in the buil-in hard distk, can be extended to an external TF also. Operaton to make it easy to use.
● After turning on the camera, menu will show up click and play.
| Specification | Model | XSP-16.0 |
| Series | Integrated display camera | |
| Sensor size | 1/2.5" | |
| Effective pixel | 5 million pixels | |
| Resolution | 2048*1536@15FPS | |
| Screen Resolution | 2048*1536 Retinal Screen | |
| Output | USB2.0, HDMI, TF card, WIFI | |
| Pixel size | 2.2*2.2μm | |
| Power | DC-12V/2A | |
| Features | UI | Easy mouse control, , Android5.1 operation system |
| Mark function | Point coordinates, Reticle, Coordinates, Text annotation | |
| Length measurement | Straight length, broken line length, curve line length, distance between parallel lines,point-line distance | |
| Center distance of circles | Center distance of circles | |
| Geometry measurement | Line length, radius setting circle, two points setting circle, three points setting circle, concentric circles | |
| Geometry area | Polygon,Square | |
| Image capture | Support 16 million static image capture | |
| Videorecord | Supports 1080P video | |
| Measurement tool | S-EYE | |
| Package | Size | 238.00*51.00*206.00mm |
| Weight | 0.6kg | |
| Accessory | DC-12V Power adapter |
